IECEx Approved Pressure and Vacuum Feedthroughs

Series PF - Feedthroughs for single elements

These feedthroughs are designed for sealing single elements, usually sensors, probes or tubes, where they penetrate a pressure or environmental boundary.

Common applications include sealing sheathed thermocouples and resistance thermometers, small-bore tubes and other types of sensor where they enter a process enclosure.

Series PF feedthroughs seal elements from 0.5mm dia. to 25.4mm (1"). There are five body sizes having 1/8”, 1/4”, 1/2”, 3/4” and 1” process connections with BSPT (conical gas or DIN 2999 ‘R’) and NPT threads.

Spectite® feedthroughs are designed for ease of assembly and installation. Elements can be adjusted, removed and replaced when not under pressure or vacuum conditions.
  • IECEx Approved to Ex II 2 GD, Ex d IIC Gb / Ex e IIC Gb, Ex ta IIIC Da
  • Seal on probes, sensors, small-bore tubes and other similar elements
  • Immersion length of the element can be easily adjusted
  • Five sizes of feedthrough assembly
  • Designed for easy installation of single elements 0.5mm to 25.4mm (1”) diameter
  • Pressure range: Vacuum to 700 bar*
  • Temperature range: -60°C to +450°C*
  • Stainless steel body (316L), internal metal components and cap
  • Choice of three sealant materials
  • Reusable fitting – internal components replaceable
  • * Dependent on sealant and fitting selected
